The network camera requests access to the protected LAN via the authenticator (a
switch).
The switch forwards the identity and password to the authentication server (RADIUS
server).
The switch forwar ds the certificate of authentication server to the network camera.
If all the information is validated, the switch allows the network access to the protected
network.
Steps:
1. Connect the network camera to your PC directly with a network cable.
2. Enter the 802.1X Settings interface:
Configuration > Advanced Configuration > Network > 802.1X
3. Check the Enable IEEE 802.1X checkbox to enable it.
4. Configure the 802.1X settings, including user name and password.
Note: The EAP-MD5 version must be identical with that of the router or the switch.
5. Enter the user name and password (issued by the CA) to access the server.
6. Click to finish the settings.
Note: The camera reboots when you save the settings.
7. After the configuration, connect the camera to the protected network.

6.3.7 Configuring QoS Settings

Purpose:
QoS (Quality of Service) can help solve the network delay and network congestion by configuring
the priority of data sending.
Steps:
1. Enter the QoS Settings interface:
Configuration >Advanced Configuration > Network > QoS
Figure 6-17 802.1X Settings
