Starting Live V Iew - Provision ISR Ultra-Z IP series User Manual

Descriptions of the live view page:
Menu Bar
Live View Parameters
Live view window
Menu Bar:
Click each tab to enter Live View, Playback, Log and Configuration page respectively.
Live View Window: Display the live video.
Toolbar: Operations on the live view page, e.g., live view, capture, record, audio on/off, two-
way audio, etc.
PTZ Control: Panning, tilting, focusing and zooming actions of the PTZ. The lighter, wiper, one-touch
focus and lens initialization control.
Preset/patrol/pattern: Set and call the preset/patrol/pattern for the PTZ.
Live View Parameters: Configure the image size and stream type of the live video.

4.3 Starting Live V iew

In the live view window as shown in Figure 4-3, click
the PTZ.
Toolbar
Figure 4-2 Live View Page
Figure 4-3 Start Live View
Click to show or hide
PTZ control pane
Preset/patrol/pattern
on the toolbar to start the live view of
12
