6. Click to activate above settings.

6.5.3 Configuring Text Overlay Settings

Purpose:
You can customize the text overlay.
Steps:
1. Enter the Text Overlay Settings interface:
Configuration > Advanced Configuration > Image > Text Overlay
2. Check the checkbox in front of textbox to enable the on-screen display.
3. Input the characters in the textbox.
4. Use the mouse to click and drag the red text frame
adjust the text overlay position.
5. Click .
Note: There are up to 8 text overlays configurable.

6.6 Configuring and Handling Alarms

Purpose:
This section explains how to configure the network PTZ to respond to alarm events, including
motion detection, external alarm input, video loss, tamper-proof and exception. These events
can trigger the alarm actions, such as Notify Surveillance Center, Send Email, Trigger Alarm Output,
etc.
For example, when an external alarm is triggered, the network PTZ sends a notification to an e-
mail address.
2015-01-18 Sunday 14:38:05
Figure 6-38 Adjust OSD Location
in the live view window to
44
