10
SET MODE

■ Items in the Set mode

Item
LCD BACKLIGHT
BEEP
BAND EDGE BEEP
BEEP LEVEL
BEEP LEVEL LIMIT
RF/SQL CONTROL
METER PEAK HOLD
QUICK SPLIT
SPLIT LOCK
XFC
AUTO TUNE
PTT TUNE
MODULATION INPUT
(DATA OFF)
MODULATION INPUT
(DATA ON)
USB LEVEL
SPEECH LEVEL
SPEECH LANGUAGE
SPEECH SPEED
SPEECH S-LEVEL
SPEECH [MODE] KEY
SCAN SPEED
SCAN RESUME
MAIN DIAL AUTO TS
DIAL 1 ⁄ 4
Range or Value
(Default is shown in bold)
HI (High), Lo (Low) or oF
(Off)
on or oF
on or oF
0 ~ 50 ~ 100%, in 1% steps
on or oF
rS (RF+SQL), Sq (SQL) or
At (AUTO)
on or oF
on or oF
on or oF
on or oF
on or oF
on or oF
M (MIC), A (ACC),
MA (MIC/ACC) or U (USB)
M (MIC), A (ACC),
MA (MIC/ACC) or U (USB)
0 ~ 50 ~ 100%, in 1% steps
0 ~ 50 ~ 100%, in 1% steps
En (English) or
JP (Japanese)
HI (faster) or Lo (slower)
on or oF
on or oF
HI (faster) or Lo (slower)
on or oF
HI (Fastest), Lo (Faster)
or oF (OFF)
on or oF
10-7
Descriptions
Sets the brightness of the LCD.
Turns the Confirmation beep ON or OFF.
Turns the Band edge beep ON or OFF.
Sets the maximum volume level for the con-
firmation beep and band edge beep tones
Turns the beep tones output level limiting
ON or OFF.
Selects the RF/SQL Control function.
Turns the meter peak hold function ON or
OFF.
Turns the Quick split function ON or OFF.
Turns the Split Lock function ON or OFF.
Turns the XFC (transmit frequency check)
function ON or OFF.
Turns the Auto tune function ON or OFF.
Turns the PTT Tune function ON or OFF.
Selects the desired connector(s) for modu-
lation input when the SSB data/AM data
mode is not in use.
Selects the desired connector(s) for modu-
lation input when the SSB data/AM data
mode is in use.
Sets the input modulation level of the USB
jack.
Sets the volume level of the speech func-
tion.
Selects English or Japanese as the lan-
guage of the speech function.
Selects the speech speed.
Turns the S-Level Speech announcement
function ON or OFF.
Turns the Speech [MODE] key function ON
or OFF.
Sets the rate at which channels or frequen-
cies are scanned during scanning.
Turns the Scan resume function ON or
OFF.
Set the Main Dial automatic tuning speed
when rotating [DIAL] rapidly.
Turn the ¼-speed tuning function ON or OFF
in the CW, RTTY and SSB data modes.
Refer
p. 10-9
p. 10-10
p. 10-11
p. 10-12
p. 10-13
