10
SET MODE
Items in the Quick Set mode (Continued)
■
Data mode
Turn the data mode ON or OFF.
When the data mode is turned ON, the audio, input
from the [ACC] connector, the [MIC] connector, or the
[USB] connector, is used depending on the selection
in the Set Mode. (p. 10-11)
The speech compressor function is automatically
turned OFF.
on : Data mode operation is enabled.
(" " appears.)
oF : Data mode operation is disabled.
(" " disappears.)
Key speed
Adjusts the CW key speed to between 6 and 60* wpm
(words per minute).
* 39, 43, 45, 47, 49, 51, 53, 55, 56, 58 and 59 cannot be
selected.
CW tone pitch
Adjusts the CW receive tone pitch to between 300
and 900 Hz, in 10 Hz steps.
Side tone level
Adjusts the CW side tone level to between 0% and
100%, in 1% steps.
Side tone level limit
Turn the CW side tones output level limiting capability
ON or OFF.
When this item is set to ON, the CW side tone is
linked to the [AF] control until rotation of the [AF] con-
trol reaches the specified level—further rotation will
not increase the volume of the CW side tones.
on : The CW side tone level is limited with the [AF]
control.
oF : The CW side tone level is linked to the [AF]
control.
(SSB/AM modes)
(CW mode)
(CW mode)
(CW mode)
(CW mode)
10-5
OFF (default)
20 WPM (default)
600 Hz (default)
30% (default)
ON (default)
