11
CONTROL COMMAND

■ Controlling the radio with CI-V

D CI-V connection example
The transceiver can be connected through an optional
CT-17 -
ci v level converter
equipped with an RS-232C port. The Icom Commu-
nication interface-V (CI-V) controls the following func-
tions of the transceiver.
Up to four Icom CI-V transceivers or receivers can be
connected to a personal computer equipped with an
RS-232C port. See page 10-16, 10-17 to set the CI-V
option in the Set mode.

D Data format

The CI-V system can be operated using the following
data formats. Data formats differ according to com-
mand numbers. A data area is added for some com-
mands.
CONTROLLER TO IC-7200
FE
IC-7200 TO CONTROLLER
FE
to a personal computer
q w e r t
FE 76 E0 Cn Sc Data area
q w e r t
FE E0 76 Cn Sc Data area
IC-7200
y u
FD
y u
FD
11-2
9−15V DC
RS-232C
cable
ct-17
mini-plug cable
OK MESSAGE TO CONTROLLER
FE FE E0 76 FB FD
NG MESSAGE TO CONTROLLER
FE FE E0 76 FA FD
PC
