Items in the Quick Set mode

Refer to pages 28, 29 for details.
Item
RF POWER L (Low) and 1 to 100%, in 1 % steps
MIC GAIN 0 ~ 50 ~ 100%, in 1 % steps
DATA MODE on or oF
6 ~ 20 ~ 60* wpm (words per minute).
KEY SPEED
* 39, 43, 45, 47, 49, 51, 53, 55, 56, 58 and 59 cannot be selected.
CW TONE PITCH 300 ~ 600 ~ 900 Hz, in 10 Hz steps
SIDE TONE LEVEL 0% ~ 30 ~ 100%, in 1% steps
SIDE TONE LIMIT on or oF
on or oF
TWIN PEAK FILTER
RTTY MARK TONE 1275, 1615 or 2125 Hz
RTTY SHIFT 170, 200, 425 or 850 Hz
RTTY KEY POLARITY n (Normal) or r (Reverse)
■

Items in the Set mode

Item
LCD BACKLIGHT HI (High), Lo (Low) or oF (Off)
BEEP on or oF
BAND EDGE BEEP on or oF
BEEP LEVEL 0 ~ 50 ~ 100%, in 1% steps
BEEP LEVEL LIMIT on or oF
RF/SQL CONTROL rS (RF+SQL), Sq (SQL) or At (AUTO)
METER PEAK
on or oF
HOLD
QUICK SPLIT
on or oF
SPLIT LOCK on or oF
XFC on or oF
AUTO TUNE on or oF
PTT TUNE on or oF
MODULATION M (MIC), A (ACC), MA (MIC/ACC) or
INPUT (DATA OFF) U (USB)
MODULATION M (MIC), A (ACC), MA (MIC/ACC) or
INPUT (DATA ON) U (USB)
USB LEVEL 0 ~ 50 ~ 100%, in 1% steps
Range or Value
(Default is shown in bold)
NOTE: The RTTY mark frequency (2125 Hz) and shift
width (170 Hz) are automatically set when the twin peak
filter is ON.
Range or Value
(Default is shown in bold)
SSB
4
4
4
-
-
-
-
-
-
-
-
Descriptions
Sets the brightness of the LCD.
Turns the Confirmation beep ON or OFF.
Turns the Band edge beep ON or OFF.
Sets the maximum volume level for the
confirmation beep and band edge beep
tones.
Turns the beep tones output level limiting
ON or OFF.
Selects the RF/SQL Control function.
Turns the meter peak hold function ON or
OFF.
Turns the Quick split function ON or OFF.
Turns the Split Lock function ON or OFF.
Turns the XFC (transmit frequency check)
function ON or OFF.
Turns the Auto tune function ON or OFF.
Turns the PTT Tune function ON or OFF.
Selects the input connector for modula-
tion signals on the SSB/AM mode. (Data
mode is OFF.)
Selects the input connector for modula-
tion signals on the SSB data/AM data
mode. (Data mode is ON.)
Sets the input modulation level of the
USB jack.
6
SET MODE
Operating Mode
CW RTTY AM
4 4 4
4
- -
4
- -
4
- -
4
- -
4
- -
4
- -
4
- -
4
- -
4
- -
4
- -
Refer
p. 29
p. 30
p. 31
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
26
