8
SCAN OPERATION

■ Scan types

Scanning automatically searches for signals and
makes it easier to locate new stations for contact or
listening purposes. The IC-7200 has two scan types;
Programmed scan and Memory scan.
PROGRAMMED SCAN
Repeatedly scans between two scan edge frequencies
(scan edge memory channels P1 and P2).
Scan edge P1 or P2
This scan operates in the VFO mode.
■ Preparation
• Channels
For a programmed scan:
Program scan edge frequencies into scan edge mem-
ory channels P1 and P2. (p. 8-3)
For a memory scan:
Program two or more memory channels other than
scan edge memory channels.
• Scan resume ON/OFF
In the Set mode you can select the scan to resume or
cancel when a signal is detected.
Scan resume must be set to ON or OFF before starting
a scan. See page 10-13 for ON/OFF setting and scan
resume details.
• Scan speed
You can select High or Low scan speeds in the Set
mode. See page 10-13 for details.
Scan
Scan edge P2 or P1
Jump
MEMORY SCAN
Repeatedly scans all programmed memory channels that
are not blank.
Mch 2
Mch 1
Mch 199
This scan operates in the Memory mode.
• Squelch status
❍ Scan starts with the squelch open
For a programmed scan:
When the tuning step is 1 kHz or less:
The scan continues until it is manually stopped by
pushing , and does not pause*, even if signals
SCAN
are detected.
* The scan pauses when the squelch is closed and then
opens (Scan resumes after 10 seconds has passed when
the scan resume is ON; The scan is cancelled when re-
sume is OFF).
When the tuning step is more than 5 kHz:
The scan pauses on each step when the scan resume
is ON; not applicable when resume is OFF.
For a memory scan:
The scan pauses on each channel when the scan re-
sume is ON; not applicable when it is OFF.
❍ Scan starts with squelch closed
The scan stops when a signal is detected.
If you set scan resume ON in the Set mode, the scan
pauses for 10 seconds when detecting a signal, then
resumes. When a signal disappears while the scan is
paused, scanning resumes 2 seconds later.
NOTE: If the [RF/SQL] control function is set to
"AUTO," the squelch is always open in the SSB, CW
and RTTY modes. (pp. 1-7, 3-12, 10-10)
8-2
BLANK
Mch 3 Mch 4
Mch 5
Mch 7 Mch 6
