SET MODE

■ Items in the Quick Set mode

Item
RF POWER
MIC GAIN
DATA MODE
KEY SPEED
CW TONE
PITCH
SIDE TONE
LEVEL
SIDE TONE
LIMIT
TWIN PEAK
FILTER
RTTY MARK
TONE
RTTY SHIFT
RTTY KEY
POLARITY
RF power
Adjusts the RF output power to between L (Low), and
1% to 100%, in 1% steps.
Mic gain
Adjusts microphone gain to between 0% and 100%,
in 1% steps.
Range or Value
(Default is shown in bold)
L (Low) and 1 to 100%, in 1% steps
0 ~ 50 ~ 100%, in 1% steps
on or oF
6 ~ 20 ~ 60* wpm (words per minute).
* 39, 43, 45, 47, 49, 51, 53, 55, 56, 58
and 59 cannot be selected.
300 ~ 600 ~ 900 Hz, in 10 Hz steps
0 ~ 30 ~ 100%, in 1% steps
on or oF
on or oF
NOTE: The RTTY mark frequency
(2125 Hz) and shift width (170 Hz)
are automatically set when the twin
peak filter is ON.
1275, 1615 or 2125 Hz
170, 200, 425 or 850 Hz
n (Normal) or r (Reverse)
(all modes)
(SSB/AM modes)
Descriptions
Adjusts the RF output power.
Adjusts the microphone gain.
Turn the data mode ON or OFF.
Adjusts the CW key speed.
Adjusts the CW receive tone pitch.
Adjusts the CW side tone level.
Turn the CW side tones output lev-
el limiting capability ON or OFF.
Turn the twin peak filter ON or
OFF.
Sets the RTTY mark frequency.
Sets the RTTY shift width.
Sets the RTTY keying polarity.
10-4
Operating
Mode
All
SSB/AM
SSB/AM
CW
CW
CW
CW
RTTY
RTTY
RTTY
RTTY
100% (default)
50% (default)
Refer
p. 10-4
p. 10-5
p. 10-6
