10
SET MODE
Items in the Set mode (Continued)
■
Item
MIC UP/DOWN SPEED
SSB/CW SYNCHRONOUS
TUNING
CW NORMAL SIDE
BREAK-IN
BREAK-IN DELAY
DOT/DASH RATIO
PADDLE POLARITY
KEYER TYPE
MIC UP/DOWN KEYER
MODE SELECT (SSB)
MODE SELECT (CW)
MODE SELECT (RTTY)
MODE SELECT (AM)
CI-V BAUD RATE
CI-V ADDRESS
CI-V TRANSCEIVE
REFERENCE FREQUEN-
CY ADJUSTMENT
Range or Value
(Default is shown in bold)
HI (faster) or Lo (slower)
on or oF
L (LSB) or U (USB)
oF (OFF), SE (Semi) or
FL (Full)
0.2 ~ 7.5 ~ 13.0 (dots), in
0.1 dots steps
1:1:2.8 ~ 1:1:3.0 ~ 1:1:4.5,
in 0.1 unit steps.
n (Normal) or r (Reverse)
EL (ELEC-KEY),
bG (BUG-KEY) or
St (Straight key)
on or oF
on or oF
on or oF
on or oF
on or oF
300, 1200, 4800, 9600,
19200 bps or Auto.
76h
on or oF
0 ~ 100%, in 1% steps
( Default setting is different
for each transceiver.)
10-8
Descriptions
Sets the rate at which frequencies are
scanned when the microphone [UP]/[DN]
keys are held down.
Turns the displayed frequency shift function
ON or OFF.
Select the carrier point of CW mode be-
tween LSB and USB.
Selects the CW break-in type.
Sets the break-in delay time for CW semi
break-in operation.
Sets the internal electronic keyer dot/dash
ratio.
Sets the paddle polarity.
Selects the keyer type for the [KEY] con-
nector on the rear panel.
Sets the activation of the microphone [UP]/
[DN] switches as a paddle.
Turns the SSB (LSB/USB) mode selection
ON or OFF.
Turns the CW/CW-R mode selection ON or
OFF.
Turns the RTTY/RTTY-R mode selection
ON or OFF.
Turns the AM mode selection ON or OFF.
Sets the CI-V data transfer rate.
Sets the CI-V address.
Turn the CI-V Transceive function ON or
OFF.
Sets the internal reference signal frequen-
cy.
Refer
p. 10-13
p. 10-14
p. 10-15
p. 10-16
p. 10-17
