11.4.7

Trusted Computing Submenu

Feature
Security Device Support
Note
Additional lines are shown in this submenu if a TPM device is connected.
11.4.8

RTC Wake Settings Submenu

Feature
RTC Wake Mode
Wake up hour
Wake up minute
Wake up second
11.4.9

ACPI Submenu

Feature
Enable ACPI Auto Configuration
Hibernation Support
ACPI Sleep State
Lock Legacy Resources
S3 Video Repost
ACPI Low Power S0 Idle
Copyright © 2016 congatec AG
Options
Disable
Enable
Options
Disabled
Wake from S4 and S5
Wake from S3, S4 and S5
0
0
0
Options Description
Disabled Enable or disable BIOS ACPI auto configuration.
Enabled
Disabled Enable or disable system's ability to hibernate (operating system S4 sleep state).
Enabled Note: Ensure that your operating system supports this feature if you want to use it.
Suspend Disabled Select the state used for ACPI system sleep/suspend.
S3 (Suspend to RAM)
Disabled Enable or disable locking of legacy resources.
Enabled
Disabled Enable or disable video BIOS re-post on S3 resume.
Enabled Note: Enable this feature if it is required by your operating system.
Disabled Enable or disable ACPI low power S0 idle support.
Enabled
Description
Enable or disable BIOS support for security device. Operating system will not show the
security device. TCG EFI protocol and INT1A interface will not be available.
Description
Set system wake mode on alarm event.
Enable this feature to wake from the specified Sx states on the hr::min::sec as specified.
Specify wake up hour. For example: Enter 3 for 3am and 15 for 3pm.
Specify wake up minute.
Specify wake up second.
TSSLm11.indd 91/132
