Feature
Automatic Critical Trip Point
Critical Trip Point Value
Lid Support
Sleep Button Support
Note
The congatec COM Express Type 6 and Type 10 modules use a Push-Pull output for the fan_pwm signal instead of the open drain output
specified in the COM Express specification. Although this does not comply with the COM Express specification 2.0, the benefits are obvious.
The Push-Pull output optimizes the power consumed by the fan_pwm signal without functional change.
11.4.7

RTC Wake Submenu

Feature
Wake System At Fixed Time
Wake up hour
Wake up minute
Wake up second
11.4.8

Trusted Computing Submenu

Feature
Security Device Support
TPM State
Copyright © 2013 congatec AG
Options Description
Enabled = Configure the critical trip point - the temperature threshold at which the ACPI aware OS performs
Disabled
Enabled a critical shutdown - automatically to recommended value.
Disabled = Configure the critical trip point manually.
Specifies the temperature threshold at which the ACPI aware OS performs a critical shutdown.
71 C, 79 C, 87 C,
95 C, 103 C, 106 C,
111 C, 119 C, 127 C
Configure COM Express LID# Signal to act as ACPI lid.
Disabled
Enabled
Configure COM Express SLEEP# signal to act as ACPI sleep button.
Disabled
Enabled
Options Description
Disabled Enable system to wake from S5 using RTC alarm.
Enabled
Specify wake up hour. For example, enter "3" for 3am and "15" for 3pm.
Specify wake up minute.
Specify wake up second.
Options Description
Disabled Enable or disable TPM support. System reset is required after change.
Enabled
Disabled Enable or disable TPM chip.
Enabled Note: System might restart several times during POST to acquire target state.
TU87m12 88/114
