Specification

2.1

Feature List

Table 7 Feature Summary
Form Factor
Processor
Memory
cBC
Chipset
Audio
Ethernet
Graphics
Graphic Interfaces
Back Panel I/O
Connectors
Onboard I/O
Connectors
BIOS
Copyright © 2017 congatec AG
Based on Thin Mini-ITX form factor (170mm x 170mm)
Intel Apollo Lake Atom™, Pentium and Celeron
® ®
Two memory sockets (located on the top side of the conga-IA5) with support for:
-
SO-DIMM non-ECC DDR3L modules
-
Data rates up to 1866 MT/s
- Maximum 8 GB system memory capacity
Multi-stage watchdog, manufacturing and board information, board statistics, I2C bus, Power loss control
Integrated in the SoC
High Definition Audio codec Cirrus Logic CS4207
2x Gigabit Ethernet Intel ® I211 (commercial variants) or Intel
Intel ® HD Graphics Gen9-LP supporting DirectX12, OpenGL 4.3, OpenGL ES 3.0, OpenCL 1.2, PAVP 2.0 and HDCP 1.4/2.0. HEVC (H.265), AVC
(H.264), MVC, VP8, VP9 (software encode only), and JPEG/MJPEG format decode and encode. MPEG2, VC-1, and WMV9 format decode.
2x DisplayPort++ (DP, HDMI/DVI) and 1x LVDS shared with 1x eDP 1.4
1x DC-IN (for commercial variants only)
2x DisplayPort ++ support:
-
DP
-
DVI/HDMI 1.4 (requires external passive cable adapter)
2x Gigabit Ethernet
1x LVDS (top side)
1x eDP (bottom side)
1x Backlight with selectable voltage
1x Monitor OFF
SATA Interfaces:
- 2x SATA III (6.0 Gb/s) — one featuring SATADOM
-
1x SATA power (3.3V, 5V or 12V)
-
1x 4-pin power header (5V or 12V)
PCI Express Interfaces:
-
1x M.2 slot (shared with SATA1 connector)
- 1x Half size/Full size mini PCIe/mSATA card slot
-
1x PCIe x1 card slot (shared with mini PCIe/mSATA card slot)
1x Double USB 3.0 header (only supports one port)
1x Single USB 2.0 header
1x Front panel HD audio
1x SPDIF/Digital microphone
AMI Aptio ® UEFI 5.x firmware, 8 MByte serial SPI with congatec Embedded BIOS features.
®
® I210 (industrial variants)
2x USB 2.0
2x USB 3.0/2.0
1x Line OUT
1x Mic IN
1x SD card
1x Internal stereo speaker
Connectors supported via Super IO:
- 2x COM ports
-
1x HSUART
- 1x CPU fan power with selectable voltage
-
1x System fan power with selectable voltage
-
1x Case Open Intrusion Detection header
-
GPIOs on feature connector
Feature connector (GPIOs, I2C, SPI, SMB, LPC, LID/SLEEP etc.)
1x Front panel header (Power button, reset, LEDs etc.)
1x Internal power header (12 - 24V)
Optional Interfaces (not populated by default):
-
SBM 3 signal and power support
-
ccTALK (shared with COM port)
-
SIM card slot (routed to Full Size mini PCIe)
