Specification

2.1

Feature List

Table 7 Feature Summary
Form Factor
Processor
Memory
cBC
Chipset
Audio
Ethernet
Graphics
Graphic Interfaces
Back Panel I/O
Connectors
Onboard I/O
Connectors
BIOS
Power
Management
Other Features
Security
Copyright © 2017 congatec AG
Based on Thin Mini-ITX form factor (170mm x 170mm)
Intel Apollo Lake Atom™, Pentium and Celeron
® ®
Two memory sockets (SO-DIMM non-ECC DDR3L modules, Data rates up to 1866 MT/s, Maximum 8 GB system memory capacity)
Multi-stage watchdog, manufacturing and board information, board statistics, I2C bus, Power loss control
Integrated in the SoC
High Definition Audio codec Cirrus Logic CS4207
2x Gigabit Ethernet Intel I211 (commercial variants) or Intel
®
Intel HD Graphics Gen9-LP supporting DirectX12, OpenGL 4.3, OpenGL ES 3.0, OpenCL 1.2, PAVP 2.0 and HDCP 1.4/2.0. HEVC (H.265), AVC
®
(H.264), MVC, VP8, VP9 (software encode only), and JPEG/MJPEG format decode and encode. MPEG2, VC-1, and WMV9 format decode.
2x DisplayPort++ (DP, HDMI/DVI) and 1x LVDS shared with 1x eDP 1.4
1x DC Power Jack (optional for industrial variants)
2x DP++ Ports
2x Gigabit Ethernet
1x ATX 4-Pin Connector
1x SBM Connectors (optional)
3
1x CR2032 Cell Battery Holder
1x Stereo Speakers Header
1x Digital Microphone and S/PDIF Header
1x Front Panel Audio Header
2x UART headers (ccTalk optional)
1x CPU Fan Header and 1x System Fan Header
1x USB 3.0 Header (for 1x USB 3.0 port)
1x USB 2.0 Header (for 1x USB 2.0 port)
1x SATA Power Connector
2x SATA 6Gb/s Ports (1x with support for SATADOM)
1x 4-Pin Power Header
AMI Aptio UEFI 5.x firmware, 8 MByte serial SPI with congatec Embedded BIOS features.
®
ACPI 4.0 compliant with battery support. Also supports Suspend to RAM (S3)
Configurable TDP
Ultra low standby power consumption, Deep Sx
Thermal and voltage monitoring, CMOS Battery, Beeper
congatec Standard BIOS (also possible to boot from an external BIOS by triggering the BIOS_DISABLE# signal on the feature connector)
Integrated Intel ® PTT (TPM 2.0). Infineon SLB9665 (LPC TPM 2.0) or SLB9660 (LPC TPM 1.2) available by assembly option.
®
I210 (industrial variants)
®
2x USB 2.0 and 2x USB 3.0
1x Headphone Jack
1x Microphone Jack
1x M.2 3042/2242 Card Slot
1x LVDS Header
1x eDP Connector
1x Backlight Power Header
1x Monitor OFF Header
1x PCIe x1 Card Slot
1x Mini PCIe Card Slot (Half-Size)
1x Mini PCIe Card Slot (Full-Size)
1x Micro-SIM Card Slot
1x microSD Card Slot
1x Front Panel Header
1x Chassis Intrusion Header
1x Feature Connector
