Device
Router E
Router F
Router F
Source 1
Source 2
Configuration procedure
1. Assign IP addresses and configure unicast routing:
a. Assign the IP address and subnet mask to each interface according to
shown.)
b. Configure OSPF on the routers to make sure the routers are interoperable at the network layer
in each AS, and they can dynamically update routing information. (Details not shown.)
2. Enable IP multicast routing, enable PIM-SM and IGMP, and configure a PIM-SM domain border:
# Enable IP multicast routing on Router A, enable PIM-SM on each interface, and enable IGMP on
the host-side interface Ethernet 1/3.
<RouterA> system-view
[RouterA] multicast routing-enable
[RouterA] interface ethernet 1/1
[RouterA-Ethernet1/1] pim sm
[RouterA-Ethernet1/1] quit
[RouterA] interface ethernet 1/2
[RouterA-Ethernet1/2] pim sm
[RouterA-Ethernet1/2] quit
[RouterA] interface ethernet 1/3
[RouterA-Ethernet1/3] igmp enable
[RouterA-Ethernet1/3] pim sm
[RouterA-Ethernet1/3] quit
# Enable IP multicast routing, PIM-SM, and IGMP on Router B, Router C, Router D, Router E, and
Router F in the same way. (Details not shown.)
# Configure a PIM domain border on Router B.
[RouterB] interface pos 5/0
[RouterB-Pos5/0] pim bsr-boundary
[RouterB-Pos5/0] quit
# Configure PIM domain borders on Router C and Router E in the same way. (Details not shown.)
3. Configure C-BSRs and C-RPs:
# Configure Loopback 0 as a C-BSR and a C-RP on Router B.
[RouterB] pim
[RouterB-pim] c-bsr loopback 0
[RouterB-pim] c-rp loopback 0
[RouterB-pim] quit
# Configure C-BSRs and C-RPs on Router C and Router E in the same way. (Details not shown.)
4. Configure BGP and configure mutual route redistribution between BGP and OSPF:
# Configure an eBGP peer, and redistribute OSPF routes on Router B.
Interface
Loopback 0
Ethernet 1/1
Ethernet 1/2
—
—
183
IP address
3.3.3.3/32
10.110.6.2/24
10.110.7.1/24
10.110.2.100/24
10.110.5.100/24
Figure 54. (Details not
