LOG Logoff and Disconnect
LOG is used to terminate an X.25 session. It causes the PAD to clear any active X.25 calls,
disconnect and return to AT command mode.
PAR? List Local X.3 Parameters
PAR? lists the local X.3 parameters for the current session.
PROF Load/Save PAD Profile
The PROF command is used to store or retrieve a pre-defined set of X.3 PAD parameters (referred
to as a PAD profile). The information is stored in system file called X3PROF. There are four pre-
defined profiles numbered 50, 51, 90 and 91. Additionally, you may create four "user PAD
profiles" numbered 1 to 4.
Profile 50 is automatically loaded when a PAD is first activated. To load one of the other pre-
defined profiles use the PROF command followed by the required profile number. For example:
PROF 90
To create a User PAD profile you must use the SET command to configure the various PAD
parameters to suit your application and then use the PROF command in the format:
PROF &nn
where "nn" is the number of the User PAD profile to be stored, such as 03. Alternatively,
you may use the web interface to edit the parameters directly (Configuration -
Network > Legacy Protocols > X.25 > PADs n-n > PAD n > PAD Settings).
The pre-defined profiles (50, 51, 90, 91), cannot be overwritten and are permanently
configured as shown in the following table:
Parameter
1
2
3
4
5
6
7
8
9
10
11
12
Digi TransPort User Guide
Profile
50 51 90 91
1 0 1 0
0 0 1 0
0 0 126 0
5 5 0 20
0 3 1 0
5 5 1 0
0 8 2 2
0 0 0 0
0 0 0 0
0 0 0 0
15 15 15 15
0 3 1 0
