- Page 1 2000 Series Routers ISDN Terminal Adapter ISDN Router Installation Guide...
- Page 2 Digi International reserve the right to modify or revise all or part of this document, its contents, and any products described herein at any time without prior notification and shall not be responsible for any loss, cost, or damage, including consequential damage, caused by reliance on these materials.
- Page 3 Any attempt to service or repair the unit by the user will void the product warranty. The TA2020B and IR2110B are designed for indoor use only and should be used in an environment that is suitable for computers and other electronic equipment.
- Page 4 TA2020B & IR2110B Installation Guide Preface This guide describes the installation procedure for the TA2020B and IR2110B. It is intended to provide sufficient information for you to be able to connect the unit to your terminal equipment and power supply. A complete reference guide to the software features that are available on the product is available separately in PDF format that can be downloaded from the Digi International website (www.digi.com).
-
Page 5: Front Panel Features
TA2020B & IR2110B Installation Guide 1 Introduction The TA2020B and IR2110B facilitate the transmission of data over ISDN networks. The units can be configured either by using commands entered at the serial port (much like a modem), or via the built-in Web interface. We recommend that you use the Web interface whenever possible. - Page 6 To comply with EMC requirements it should not be used with a longer cable. On the TA2020B this 9-way D socket provides an asynchronous SERIAL 1 RS2322 serial port which may be used to connect the unit to a compatible serial device.
-
Page 7: Installation
TA2020B & IR2110B Installation Guide 2 Installation The TA2020B and IR2110B are designed for indoor use (office or home). The router should be positioned on a smooth, level surface making sure that there is adequate ventilation. Do not expose the router to extremes of heat or cold, strong magnetic fields or liquids. - Page 8 TA2020B & IR2110B Installation Guide 3 Configuration Once the TA2020B or IR2110B has be installed and powered up, you must now configure the unit so that it can communicate with your network and the Internet. 3.1 Configuring the TA2020B The TA2020B is configurable only through its serial port.
- Page 9 TA2020B & IR2110B Installation Guide Check the Don't detect my modem, I will select it from a list option before clicking Next > to display the following dialog screen: This screen lists the manufacturers and models of modem currently available on your system.
- Page 10 You must now enter a name for the connection. It is helpful to choose a name that you will easily remember such as “My Local TA” or “TA2020B - Bristol Office”. Click Next >. The next dialog allows you to fill in the phone number for the connection.
- Page 11 TA2020B & IR2110B Installation Guide Step 3 – Configuring the new DUN connection The new DUN connection that you have just created may now be used to connect to the unit but before you do this, you will need to check some of the configuration properties.
- Page 12 TA2020B & IR2110B Installation Guide Click OK when you have finished to return to the main properties dialog. Now select the Networking tab: Make sure that the Type of dial-up server I am calling is set to PPP: Windows 95/98/NT/2000, Internet and click on Settings: Make sure that all three options are unchecked before clicking OK to return to the Networking tab.
- Page 13 TA2020B & IR2110B Installation Guide Step 4 – Initiating a DUN connection In the main dialog, you are asked to enter a username and password. The default settings for your unit are “username” and “password” respectively but you should change as soon as possible in order to prevent unauthorised access to your unit (refer to the section entitled Configure >...
- Page 14 Reference guide. Step 1 – Install the Connection Wizard Download the connection wizard from the Digi website and install the software on your Step 2 – Run the Wizard Once the wizard has been installed on your PC, run it from the Windows Start menu.
-
Page 15: General Specifications
TA2020B & IR2110B Installation Guide 1 General Specifications Model numbers 81-TA2020B-SSEU-00 81-IR2110B-SSEU-00 Power supply 12V DC / 1.5A Dimensions W162 x D130 x H32 mm Weight 0.53Kg Operating temp. -20 to +50 degree Celsius range ISDN modem Full duplex 2B+D S/T interface transceiver (according to ITU- T I.430). -
Page 16: Declaration Of Conformity
TA2020B & IR2110B Installation Guide 2 Declaration of Conformity Declaration of Conformity for R&TTE Directive Digi International Ltd. Beacon House, Riverside Business Park, Ilkley, West Yorkshire, LS29 8JZ ENGLAND declare under our sole responsibility that the following product(s): Models: TA2020B, IR2110B...
