To configure the PPP Sub-Configs parameters set the following values:
Enable QoS on this interface
This checkbox, when checked, reveals the following QoS configuration parameters:-
• Link speed n Kbps: The value in this text entry box should be set to the maximum data
rate that this PPP link is capable of sustaining. This is used when calculating whether or not
the data rate from a queue may exceed its minimum Kbps setting as determined by the
profile assigned to it and send at a higher rate (up to the maximum Kbps setting).
• Queue n: Below this column heading, is a list of ten queue instances. Each instance is
associated with the profile and priority on the same row.
Profile n: This column contains the profile to be associated with the queue. There are
•
twelve available, 0 – 11, which are selected from the drop-down list boxes.
• Priority: This column contains drop-down menu boxes which are used to assign a priority
to the selected queue. The priorities available are: Very High, High, Medium, Low, and Very
Low.
Related CLI commands
Entity
qos
qos
qos
qos
Digi TransPort User Guide
Instance Parameter
n linkkbps
n q0prof
n q0prio
n q1prof
Values Equivalent Web Parameter
0 - Link speed n kbps
0 - 11 Queue 0 Profile
0 – 4 Queue 0 Priority
0 = Very high
1 = High
2 = Medium
3 = Low
4 = Very Low
0 – 11 Queue 1 Profile
Advanced Interfaces parameters
