Entity
mlppp
mlppp
mlppp
mlppp
mlppp
mlppp
mlppp
mlppp
mlppp
mlppp
mlppp
mlppp
PPP parameters
This section contains those parameters which may need to be adjusted when setting up a PPP
connection but in general can be left at their default values.
Load answering defaults
Clicking this button causes the router to read the default PPP answering default parameters
from a default configuration stored in memory.
Load dialing defaults
Clicking this button causes the router to read the PPP dialing parameters from a default
configuration stored in memory.
Description
This text box holds a description of the PPP instance that may make it easier to refer to. For
example the PPP instance used to connect to an ISP may be named MyISP.
This PPP interface will use
If the PPP mappings have been set up previously using the PPP mappings page, this box will
contain the name of the protocol that has been assigned to this PPP instance. If the mapping
Digi TransPort User Guide
Instance
Parameter
0
password
0
epassword
0
r_chap
0
l_shortseq
0
up_rate
0
up_delay
0
down_rate
0
down_delay
0
dup_rate
0
dup_delay
0
ddown_rate
0
ddown_delay
Values
Equivalent Web Parameter
Valid password
password
Encrypted
None – this parameter is not
password
configurable
ON, OFF
Enable remote CHAP authentication
ON, OFF
Enable short sequence numbers
Default OFF
0 – 2147483648
When the data rate is greater than n
Default 2000
bytes/sec
0 – 2147483648
for s seconds
Default 10
0 – 2147483648
When data rate is less than n bytes/
Default 1000
sec
0 – 2147483648
for s seconds
Default 10
0 – 2147483648
When data rate is greater than n
Default 500
bytes/sec
0 – 2147483648
for s seconds
Default 5
0 – 2147483648
When data rate is less than n bytes/
Default 500
sec
0 – 2147483648
for s seconds
Default 5
Advanced Interfaces parameters
154
