External Min Port
The value in this text box specifies the lowest port number to be redirected.
External Max Port
The value in this text box specifies the highest port number to be redirected.
Forward to Internal IP Address a.b.c.d
The value in this text box is the IP address to which packets containing the specified
destination port number are to be redirected.
Forward to Internal Port
The value in this text box specifies the IP port number to which packets containing the
specified port number are to be redirected. When set to "0", no port remapping occurs and the
original port number is used. The NAT mode parameter of the appropriate interface must be
set to "NAPT" rather than "NAT" or "OFF" for this parameter to take effect.
Related CLI commands
Entity
nat
nat
nat
nat

Command format

Nat <entry> <parameter> <value>
Example commands
To set the IP address for entry 0 in the table to 10.1.2.10 enter the command:
nat 0 IPaddr 10.1.2.10

Multicast Routes parameters

Digi TransPort routers support multicast routes, allowing them to route packets to multicast
group addresses. Up to 20 different static multicast routes may be configured.
Static multicast routes must be used in conjunction with the IGMP parameter on the outbound
interface. For example, after configuring a static multicast route for multicast traffic via PPP 1, the
IGMP parameter in Configuration – Network > Interfaces > IGMP needs setting to ON.
Multicast routing is configured using a table with the following parameters.
Digi TransPort User Guide
Instance Parameter
0 - 29 minport
0 - 29 maxport
0 - 29 IPaddr
0 - 29 mapport
Values Equivalent Web Parameter
0 - 65535 External Min Port
0 - 65535 External Max Port
Valid IP address Forward to Internal IP Address
a.b.c.d a.b.c.d
0 - 65535 Forward to Internal Port
Multicast Routes parameters
