Related CLI commands
Entity
riprx
Authentication Keys parameters
RIP authentication keys are used with the plain password and MD5 RIP authentication methods.
Key k
The value in this text box is the RIP authentication key. Enter a string of up to 16 characters
long. A current key will not be displayed.
Confirm Key
Re-enter the new key into this text box to allow the router to check that the two are identical.
Key ID (MD5 only)
The value in this text box is the ID for the key. The ID is inserted into the RIP packet when using
RIP v2 MD5 authentication and is used to look up the correct key for received packets. The
valid range is 0 – 255.
Valid from now/dd,mm,yy
These two radio buttons select, between having the validity period for the key starting
immediately of allowing a start date to be defined. The starting date is specified using a drop
down list to select the start day, a drop-down list to select the start month and a text box to
enter the start year. Selecting the Disable option from the day and None from the month
means that this key should not be used. The year can be specified as either two or four digits
(such as 11 or 2011).
Expires Never/dd,mm,yy
These two radio buttons select between defining the end date using the drop-down lists and
text box or by setting the expiration to Never. The key end day is selected from the first drop
down list, selecting Disable means that the key should not be used. The end month is selected
from the second drop-down list, selecting None means that the key should not be used. The
year is entered into the text box and can be in two or four digit format.
Digi TransPort User Guide
Instance Parameter
0 - 9 IPaddr
Values Equivalent Web Parameter
Valid IP address IP Address a.b.c.d
a.b.c.d
RIP parameters
