UDP Echo

When enabled, the UDP echo client generates UDP packets that contain the router's serial
number and ID and transmits them to the IP address specified by the configuration. When the
remote router receives a UDP packet on a local port and UDP echo server is configured, it will
echo the packet back to the sender. There may be more than one UDP echo instance available on
the unit. Instance 0 is used when specifying the local port to listen on.

UDP Echo n parameters

There may be instances of the UDP echo task supported by the router (model-dependent). Each
has its own configuration web page, described below. For the command line configuration, valid
instance numbers start at 0 as normal.
Enable UDP Echo
This checkbox is unchecked by default – when checked, it reveals the configuration
parameters associated with send UDP echo packets.
Send a UDP packet to IP address a.b.c.d port n every s seconds
The values in these three text boxes define the destination IP address for the UDP packets, the
port number to which they should be sent and the sending interval. If the destination IP
address is left blank, the router will not attempt to send any packets.
Use local port n
The value in this text box specifies which local port the router should listen on for UDP
packets. If any UDP packets are sent to this port, the router will send a copy back to the IP
address and port they were sent from.
Route via Routing table / Interface x,y
These two radio buttons select whether the router should use its routing table to determine
how to send the UDP packets or whether it should use the specified interface. If the specific
interface is selected, the interface is selected from the drop-down list. The options available
are PPP and Ethernet. The interface instance is specified in the adjacent text box.
Only send packet when the interface is "In Service"
