Related CLI commands
Entity
cudmap
cudmap
cudmap

IP Sockets to Protocol Switch

This page contains a table that allows you to enter a series of IP Port numbers and X.25 Call
strings as shown below. It is used to configure the unit so that IP data can be switched to any of
the protocols support by the protocol switch includingX.25. For example data that is received on
a TCP connection can be forwarded over SSL, XoT or a UDP stream. The only columns that must
be filled out are "Port" and "Number of Sockets".
This table is duplicated in the Configuration - Network > Legacy Protocols > X.25 > IP to
X.25 Call section as it can also be used to convert an incoming TCP connection to an X.25
session to be answered by PAD without using the protocol switch. It is included at this
point in the web user interface as a convenience in case the table is being used in
conjunction with PAD and not the protocol switch.
Digi TransPort User Guide
Instance Parameter
cudfrom
0-9
cudto
0-9
Interface
0-9
Values Equivalent Web Parameter
0-65536 CUD In
0-65536 CUD Out
0,1,2,3,4,12 Interface
0=Any
1=LAPD
2=LAPB 0
3=LAPB 1
4=XOT
12=LAPB 2
IP Sockets to Protocol Switch
372
