9. Procedures when leaving the printer for a long time

If you leave the printer for a long period of time (2 weeks or longer), please dispose all ink from the printer, ﬁll the

ink tubes and the print heads by the cleaning solution, cover the print heads by the wet keeping frame and the wet

keeping polyethylene ﬁlms by following procedures.

(1) Move the printhead carriage to the cleaning position.

(a) From the main menu, select [Cleaning Tool] and then press the ENTER key.

(b) From the submenu, select [Clean Post] and then press the ENTER key.

(2) Set the 3-way valve for each ink tank to the ink supply position.

(3) Empty out the ink from the ink tanks.

CAUTION:

First of all, remove the waste ink tanks mounted in the printer, and then discard the ink from the ink tanks

into the waste ink tanks.

(4) Feed out any ink remaining in the Print Head nozzles.

(a) Press the Ink button to feed out any ink through the Print Head nozzles.

(b) When the "No ink" alarm sounds, from the main menu, select [Ink Status] and then press the ENTER

key to continue the ink removal operation.

(5) Turn off the printer power supply.

(6) Empty out the ink from the sub tanks.

CAUTION:

First of all, remove the waste ink tanks mounted in the printer, and then discard the ink from the sub tanks

into the waste ink tanks.

(a) Remove the cap from each sub tank.

If the cap is difﬁcult to remove, use pliers or similar to grip the cap and open it.

(b) Empty out the ink from each sub tank.

(Refer to Section 6.1 Initial Cleaning of the Ink Supply Tubes and the Sub Tanks) Empty out the cleaning

solution from the sub tanks.)

JS310-UM-251-9370

9. Procedures when leaving the printer for a long time
