(2) Feed the media up to the take-up roller position.
(a) Set the take-up roller selector switch to the position between the "II" and "I" markings (the OFF position,
"O").
(b) From the main menu, select [Print Para] and then press the ENTER key.
(c) From the submenu, select [Print Post] and then press the ENTER key.
(d) While holding down the FUNC key, press the DOWN ARROW key to feed the media.
(f) When the media has reached the take-up roller position, with a little extra length added to facilitate the
take-up operation, release the keys.
(3) Align the take-up core with the media width.
Loosen the flange screws, and align the take-up core with the width of the media.
(4) Use a length of tape to attach the leading edge of the media to the take-up core.
JS310-UM-251-9370
Center position
Flange
Loosen these two screws
64
7. Media Loading Procedure
