3. Product Configuration

3.1 Main Unit

(6)
(9)
(10)
(1) LCD Control Panel
(2) Press roller control pole
(3) Ink tanks & Solution tank
(4) DRYER Power Socket
(5) Take-up Roller
(6) Cleaner
(7) Media Feeding Roller
(8) Waste Ink Tanks
(9) PRINTER Power Socket & HEATER Power Socket
(10) Media Feeding System
JS310-UM-251-9370 7
3. Product Configuration
(1)
(2)
(3)
(4)
(5)
(7)
(8)
