GRAPHTEC SignJet JS310-25ES Service Manual page 25

Main menu
Print Para
Application
JS310-UM-251-9370
Submenu
PH Volt. Set
UV Lamp Power
Front Heater
Pre Heater
PH Heater
18
4. Basic Panel Operation
Function description
This function is used to set Voltage of P/Hs.
The LCD displays details as below:
Menu -> PH
PH
PH
OFFLINE PH
Here press UP or DOWN ARROW key to
scroll the submenu. The LCD will display
values as below:
Menu ->1 PH
0099
0182
OFFLINE
The upper number is adjustable EF value of P/H
and the down number indicates voltage value of
P/H.
Press LEFT or RIGHT ARROW to move the
cursor position over the number string and press
UP or DOWN ARROW key to increase or
reduce the flashing number of EF value.
The 8 P/Hs setup from 1 to 8:
PH 1 Voltage for P/H C1;
PH 2 Voltage for P/H C2;
PH 8 Voltage for P/H K2.
No operation.
"45" flashes on the LCD as default setting at the
unit of centigrade degrees. Press UP or DOWN
ARROW key to increase or reduce the value of
temperature.
For normal condition, keep the default value.
"40" flashes on the LCD as default setting at the
unit of centigrade degree. Press UP or DOWN
ARROW key to increase or reduce the value of
temperature.
For normal condition keep the default value.
No operation.
1 Voltage
2 Voltage
3 Voltage
4 Voltage
1 Voltage
