4.3 LCD display for normal usage

4.3.1 LCD display during printing

Printing
TORAL: XXXX
FINISH: XXXX
ONLINE RIP READY: XXXX
The LCD displays total lines for printing, lines finished and lines of RIP ready during printing.

4.3.2 LCD display when printing is paused

P/H nozzles may be clogged during printing, so it needs cleaning.
Press and hold ONLINE key to pause the printing until the LCD displays "Busy".
The P/H carriage returns to original position after it finishes the current line printing. The LCD displays menus
as below:
Waiting 1. Ink status
2. Heat status
3. Cleaning tool
ONLINE 4. Continuous
5. Cancel
Press UP or DOWN ARROW key to select "Cleaning tool" function in the menu and execute cleaning.
Select "Continuous" to continue printing or "Cancel" to cancel printing.
JS310-UM-251-9370
Total lines for printing
Lines finished
Lines of RIP ready
21
4. Basic Panel Operation
