If you leave the printer for a long period of time (2 weeks or longer), please dispose all ink from the printer,

fill the ink tubes and the print heads by the cleaning solution, cover the print heads by the wet keeping

frame and the wet keeping polyethylene films by following procedures.

Dispose the ink from the printer

VIII.1

VIII.1.1

Move the printhead carriage to the cleaning position.

(1) From the main menu, select [Cleaning Tool] and then press the ENTER key.

(2) From the submenu, select [Clean Post] and then press the ENTER key.

(3) The printhead carriage moves to the cleaning position and then stops.

VIII.1.2

Set the 3-way valve for each ink tank to the ink supply position.

VIII.1.3

Empty out the ink from the ink tanks.

CAUTION: First of all, remove the waste ink tanks mounted in the printer, and then discard the

VIII.1.4

Feed out any ink remaining in the PrintHead nozzles.

Press the Ink button to feed out any ink through the PrintHead nozzles. When the "No ink" alarm

sounds, from the main menu, select [Ink Status] and then press the ENTER key to continue the ink

removal operation.

Continue feeding out the ink until the "No ink" alarm sounds once again.

VIII.1.5

Turn off the printer power supply.

VIII.1.6

Empty out the ink from the sub tanks.

CAUTION: First of all, remove the waste ink tanks mounted in the printer, and then discard the ink

(1) Remove the cap from each sub tank.

If the cap is difficult to remove, use pliers or similar to grip the cap and open it.

(2) Empty out the ink from each sub tank.

(3) Close the cap, and replace each sub tank.

(See section V.1 Initial Cleaning of the Ink Supply Tubes and the Sub Tanks) Empty out the

cleaning solution from the sub tanks.)
