GRAPHTEC SignJet JS310-25ES Service Manual page 50

Empty out the cleaning solution from the sub tanks
CAUTION:
First of all, remove the waste ink tanks mounted in the printer, and then discard the cleaning solution
from the sub tanks into the waste ink tanks.
(30) Remove the cap from each sub tank.
If the cap is difficult to remove, use pliers or similar to grip the cap and open it.
(31) Empty out the cleaning solution from each sub tank.
(32) Reattach the cap on each of the sub tanks, and then leave them to dry out for at least 10 minutes.
JS310-UM-251-9370
Pliers
CAUTION:
When opening the cap, be sure to grasp
the upper corners of the tank.
6. Initial Ink Induction Procedure
Tilt the sub tank, and then pour the cleaning
solution into the waste ink tank positioned
underneath it.
43
