5.4 Mounting the Waste Ink Tanks
Follow the procedure described below to mount the two waste ink tanks.
(1) Attach the waste ink tank mounting brackets to the printer.
Using the screws provided, attach one bracket to the left side and one to the right side of the printer.
(2) Connect the tubes to the waste ink tanks.
Mount the waste ink tanks on the brackets. Insert the corresponding waste liquid tubes protruding from the
printer into the opening of each waste ink tank.
CAUTION:
Store the caps that were removed from the waste ink tanks in a safe place so as not to lose them.
JS310-UM-251-9370
5. Assembling the Printer and the Installation Procedure
32
