2. Technical Parameters

Product
Printer Technique
Resolution
Color Quality
Max. Media Width
Man. Printing Width
Min. Printing Size
2
Output (m /h)
(Designed values, not from
measurement)
Display
Ink Type
Ink Supply Mode
Ink Inspection System
Printing Driver
Operation Platforms
Media Type
Media Transmission
Media Processing
Print head Height
Pre-heater & Dry System
Clamp
Print head Cleaning System
Safety System
JS310-UM-251-9370
JS310-25ES
Xaar 126 300dpi piezo head, 8 head inside
200dpi, 400dpi
Photo effect including 2 levels: Basic and High Quality
2530 mm (thickness less than 1 mm)
2471 mm
A4 or 210 mm (thickness less than 1 mm)
Mode
180 x 200 dpi 2pass
180 x 200 dpi 4-2pass
180 x 200 dpi 3pass
180 x 200 dpi 6-3pass
180 x 200 dpi 4pass
180 x 200 dpi 8-4pass
180 x 200 dpi 6pass
180 x 200 dpi 8pass
300 x 300 dpi
LCD display with 8 keys panel, self-diagnosis available
Solvent based ink: C, M, Y, K and solvent based solution
300 ml/min auto ink supply by electric pump, volume of main tank
1000 ml/color
Auto/manual ink supply, low ink detector
Support many RIP drivers
Multi-operation platforms (Windows 2000, XP, etc.)
Flex, vinyl, window film, polyester, etc.
Roll media or sheet media (bigger than A4 or 210 mm)
Auto feeding and take-up system,
weight less than 70 kg/roll
3 mm to 5 mm above media adjustable
Auto heating after electrifying, the tiptop temperature is about 40˚C
Manual adjustment media width
Auto positive pressure cleaning
Inside safety lock with auto shutting down function
5
2. Technical Parameters
JS310-18ES
1860 mm (thickness less than 1 mm)
1800 mm
2
Output (m /h)
27.5
14.5
19.2
10.5
14.5
7.5
10.5
7.5
14.5
Auto feeding and take-up system,
weight less than 40 kg/roll
