6.2 Initial Cleaning of the Cleaning Solution Supply Tubes

(1) Turn on the printer power supply.
When the power is turned on, the printer begins a self-test operation (the print head carriage and the feed
rollers move). When the self test has been completed, wait until the main menu is displayed on the LCD.
• Since ink has not yet been supplied to the printer, a "No Ink" alarm will sound after several minutes have
elapsed. This alarm does not indicate a malfunction, and no action is required.
(2) Move the print head carriage to the cleaning position.
(a) From the main menu, select [Cleaning Tool] and then press the ENTER key.
(b) From the submenu, select [Clean Post] and then press the ENTER key.
The print head carriage will move to the cleaning position and then stop.
(3) Pour approximately 150 cc of cleaning solution into the solution tank.
(4) Set the 3-way valve for the solution tank to the supply position.
(5) Set the 3-way valve for each ink tank to the cleaning position.
JS310-UM-251-9370
6. Initial Ink Induction Procedure
Solution tank 3-way valve
Ink tank 3-way valve
(4 valves)
44
Turn to the supply position
Turn to the cleaning position
