18.5 Sensor part

Item No. Part number
1 677643740
2 677642950
3 677643750
4 677642400
5 677642360
6 677648100
7 677648110
8 677642190
9 677642410
10 677642420
3
JS310-UM-251-9370
Part Name
X Encoder Sensor
Encoder Disk
Y Encoder Sensor
Original Sensor
2.5M Encoder Strip
Media Sensor
Media Sensor Bracket
Take-Up & Feed Sensor
Thermal Protector
Thermal Sensor
5
Quantity
1
1
1
1
1
1
1
2
2
4
6
122
18. Maintenance parts lists
Remark
