6. Initial Ink Induction Procedure

6.1 Initial Cleaning of the Ink Supply Tubes and the Sub Tanks

• If the power is turned off, turn it on.
• Since ink has not yet been supplied to the printer, a "No Ink" alarm will sound after several minutes have elapsed.
This alarm does not indicate a malfunction, and no action is required.
Moving the print head carriage to the cleaning position
(1) From the main menu, select [Cleaning Tool] and then press the ENTER key.
(2) From the submenu, select [Clean Post] and then press the ENTER key.
(3) The print head carriage moves to the cleaning position and then stops.
Checking that the clips on the sub tanks have been released
(4) Open the panel behind the cleaning position.
(5) Check that the tube clamper on each of the sub tanks is in the open position. If any of the clampers is in the
closed position, open it.
(6) Check that all the tube caps are closed firmly.
JS310-UM-251-9370
6. Initial Ink Induction Procedure
Tube clamper:
Check that the clampers for all four colors
are open.
Tube cap:
Tighten the caps using long-nose pliers.
Check that the tube caps for all five caps
are closed firmly.
