GRAPHTEC SignJet JS310-25ES Service Manual page 31

(3) Click the "Printer setting". Set the relevant value in the following dialogue box.
a. Select the printing resolution.
b. Select BID or single direction printing. BID has higher efficiency than single direction.
Note:
The horizontal parameters, BID compensation and feeding compensation should be adjusted already
before your printing; otherwise the printing quality will be reduced.
Details of the functions above and others referred to the Sign Jet RIP Manual
12. Click "Printing Project" to print.
13. LCD displays as below when printing:
Printing
TORAL: XXXX
FINISH: XXXX
ONLINE RIP READY: XXXX
14. If clogging appears during the printing, press ONLINE for a longer time (3s) to pause printing for print head
cleaning. After cleaning, press ONLINE to go on printing.
Cleaning procedure during printing:
P/H nozzles may be clogged during printing, so it needs cleaning.
Press and hold ONLINE key to pause the printing until the LCD displays "Busy". The P/H carriage returns to
original position after it finishes the current line printing. The LCD displays menus as below:
Waiting 1. Ink status
2. Heat status
3. Cleaning tool
ONLINE 4. Continuous
5. Cancel
Press UP or DOWN ARROW key to select "3. Cleaning tool" function in the menu and execute cleaning.
Select "Continuous" to continue printing or "Cancel" to cancel printing.
15. Press ONLINE when the printing is all finished. Then the printer is under the Offline mode.
Note:
To cancel printing operation, usually do in RIP. If you want to cancel printing directly on the printer,
press ONLINE button after the menu "printing cancel" appears in software.
JS310-UM-251-9370
Total lines for printing
Lines finished
Lines of RIP ready
24
4. Basic Panel Operation
