18. Maintenance parts lists

18.1 Recommend Parts List

Item No. Rank Part number
1 A 677646000
2 A 677642040
3 A 677642820
4 A 677642910
5 A 677642560
6 A 677643020
B 677642800
7
B 677642810
8 B 677642830
9 B 677642070
10 B 677642320
B 677642920
11
B 677642930
12 B 677642310
13 B 677642220
14 B 677642360
15 B 677642550
16 B 677642530
17 B 677642540
18 B 677642450
19 C 677642110
20 C 500053128
21 C 677642160
22 C 677642270
23 C 677642280
24 C 677642290
25 C 677642430
26 C 677642350
27 C 677642950
28 C 677643750
29 C 677643740
30 C 677642400
31 C 677642190
C 677642970
32
C 677642980
33 C 677642520
34 C 677642440
JS310-UM-251-9370
Part Name
Print Head
Print Head Control Board
X / Y Combined Board 31
PITTMAN 14207 Motor
Imported Ink Filter
3 way Valve
Main Board 31018
Main Board 31028
Ink Supply Control Board
Power Supply Assy
Y Motor Belt 320-2GT
Y-axis Belt 71
Y-axis Belt 57
2.5M X Motor Belt
Bearing 6900ZZ-NR
2.5M Encoder Strip
Whatman Air Filter
KNF Air Pump NMP-830 24V
KNF Large Ink Pump
Sub Tank
LCD Display
Control Panel Assy
Solid Relay
Motor Gear
2.5M Y Motor Pulley
2.5M Y Motor Synchro Pulley
2.5M Pinch Roller
Media Guide
Encoder Disk
Y Encoder Sensor
X Encoder Sensor
Origin Sensor
Take-Up & Release Sensor
IGUS Carriage Chain 81 Joint
IGUS Carriage Chain 89 Joint
Electric Mag Valve
Floating Switch
115
18. Maintenance parts lists
Quantity Remark
24 Xaar126-300 head
3 E100810
3 E202407B
6 E206804
15 W510100
30 W400102
2 JS310-18ES, E100703B
2 JS310-25ES, E100703C
2 E100306
2 E203101
2 W400007
2 JS310-25ES, W400260
2 JS310-18ES, W400261
2 W400080
4 W100020
2 E202901B
2 IM6240109
2 E201203
10 E201204
10 IM6220200
1 E100101
1 WCP001
2 E206601
2 VM2090614
1 IM2090203
1 IM2090402
4 SP001
2 IIM0070006
1 VM6080013
1 E110103
1 E110102
1 E200301
2 E205002B
1 JS310-18ES, W400400
1 JS310-25ES, W400265
1 E207001
2 E201106
