(5) Insert conductors fully into proper terminals and tighten them.
WIRED
Terminal
GND
WIRE
INSULATED
CAUTION:
If not connect cables into correct positions, it will damage the cable and machine, resulting in a fire
hazard or electrical shock.
(6) Put the head of the plug and tighten the screws.
(7) Select the "smaller" side to set the proper core gage.
smaller
(8) Tighten the screws to fix the cable.
JS310-UM-251-9370
17. AC cable alteration procedure from CEE to NEMA
INSULATED
Conductor Cable Color
Green or (Green/Yellow)
White or Gray
Brown (Not White, Not Green)
Screws
Screws
114
GND (Green Terminal)
