Feeding the cleaning solution in the sub tanks through the inlet tubes
(25) Position the end of each inlet tube so that it faces the waste liquid slot underneath.
(26) Press the Ink button at the cleaning position to feed the cleaning solution through the inlet tubes.
Continue to feed the cleaning solution through the tubes until they are clean (approximately 20 seconds).
CAUTION:
Take care not to get cleaning solution stains on your clothing.
Feeding out any cleaning solution remaining in the inlet tubes
(27) Press the Ink button to feed out any cleaning solution remaining in the inlet tubes. When the "No ink" alarm
sounds, from the main menu, select [Ink Status] and then press the ENTER key to continue the cleaning
solution removal operation.
(28) Continue feeding out the cleaning solution until the "No ink" alarm sounds once again.
(29) Turn off the printer power supply.
JS310-UM-251-9370
6. Initial Ink Induction Procedure
Ink button
