Main menu
Application
JS310-UM-251-9370
Submenu
Media Detect
Media Offset
Take Up Detect
T Neg. Pressure
Curve of ink
19
4. Basic Panel Operation
Function description
Press ENTER to execute the operation, the
LCD displays OFF means the function is switch
off when the printer is waiting.
OFF (function switch off)
Press UP or DOWN ARROW key to switch on
the function.
ON (function switch on)
Pull up the press pole and then pull it down, the
LCD displays details as below:
Menu Media Detect
Star: 0000mm
Lenth: 0000mm
OFFLINE
Press ENTER key to start media edge
detecting. Press ESC to cancel the operation.
After detecting, "OK" displays means the
detecting is successful and saves the result as
print position, which should add the value of
offset set at below step. "Error" displays means
the detecting is failed and the value of print
position does not change.
"XXXX" flashes on the LCD. Press Up or
Down key to increase or reduce the value. This
value added to the value of media detecting is
saved as the value of print position.
No operation.
No operation.
Select ink curves in the 12 options from 0 to 11.
LCD displays details as below:
1 2 3 4
The name of ink curve indicates as below.
1. Xr stands for XAAR print head.
2. 2 stands for 200 dpi print head.
3 stands for 300 dpi print head.
3. S stands for solvent based ink type.
O stands for oil based ink type.
U stands for UV ink type.
4. Ink name
