4.2 Description of menu function

Main menu
Ink Status
Heat Status
Cleaning Tool
JS310-UM-251-9370
Submenu
Ink Status
Ch A C M Y K c m
Rn _ _ _ _ _ _ _
Al _ _ _ _ _ _ _
Heat Status
FH Pre P/H
Tem 00 00 00
Set 00 00 00
Firing
Jam Test
Clean POS
Home Post
Auto Clean
15
4. Basic Panel Operation
Function description
Ink status displays.
The LCD display details as below:
Ink Status
Cha C M Y K cm
Rn _ _ _ _ _ _ _
Al _ _ _ _ _ _ _
Item Ch: stands for ink channels. A means all
channels;
Item Rn: displays ink supply status of
corresponding channel;
Item AL: displays ink lack alarming of
corresponding channel; Press ENTER to refill
ink and cancel alarming.
Heating status displays.
The LCD display details as below:
Heat Status
FH Pre P/H
Tem 00 00 00
Set 00 00 00
Item Tem: displays actual temperature;
Item Set: displays setup temperature.
Press ENTER key to execute the operation,
"Busy" flashes on the LCD. P/Hs spray
downward to prevent nozzle clogs. The LCD
stops flashing after firing finishes.
Press ENTER key again to execute P/H firing
one more time if necessary.
Press ENTER key to execute the operation of
test printing.
Press ENTER key to execute the operation of
moving P/H carriage to cleaning position.
Press ENTER key execute the operation of
returning the P/H carriage to original position.
Press ENTER key execute the operation of
negative pressure cleaning automatically.
