(6) Feed the cleaning solution through the inlet tubes.
(a) Position the end of each inlet tube so that it faces the waste liquid slot underneath.
(b) Press the Solution button at the cleaning position to feed the cleaning solution through the inlet tubes.
(c) Hold down the Solution button until the cleaning solution passes through the tubes.
CAUTION:
Take care not to get cleaning solution stains on your clothing.
(7) Empty out the cleaning solution from the solution tank.
CAUTION:
First of all, remove one of the waste ink tanks mounted in the printer, and then discard the cleaning
solution from the solution tank into the waste ink tank.
(8) Feed out any cleaning solution remaining in the inlet tubes.
Press the Solution button once again to feed out any cleaning solution remaining in the inlet tubes.
Continue holding down the button until all the fluid has been removed from the tubes.
JS310-UM-251-9370
6. Initial Ink Induction Procedure
Ink button
