8.2 Installing the Printer Adjustment Utility Software "Try"

CAUTION:
Do not connect the printer via the USB cable to your computer before installing the "Try USB driver".
(1) Insert the "Try" CD in your computer's CD drive.
(2) Double-click the icon of setup.exe in the "Try Setup.Graphtec V*.*" folder to run the Setup.
(3) Specify the destination folder on the following display, and then click the "Next >".
(4) Select the setup mode at the following displays, and then click the "Next >".
Typical: Installs the "Program Files", "Samples", "Card Components" and "USB Components" files.
(Recommended).
Compact: Installs the "Program Files" files.
Custom: Installs the files selected from "Program Files", "Samples", "Card Components" and "USB
Components".
JS310-UM-251-9370
8. Print Head Adjustment Procedures
70
