Initial Cleaning Of The Cleaning Solution Supply Tubes - GRAPHTEC SignJet JS310 Series Setup Manual

V.1.16 Empty out the cleaning solution from the sub tanks.
CAUTION: First of all, remove the waste ink tanks mounted in the printer, and then discard the
(1) Remove the cap from each sub tank.
If the cap is difficult to remove, use pliers or similar to grip the cap and open it.
(2) Empty out the cleaning solution from each sub tank.
V.1.17 Leave the tanks and tubes to dry out.
Replace the cap on each of the sub tanks, and then leave them to dry out for at least 10 minutes.

Initial Cleaning of the Cleaning Solution Supply Tubes

V.2
V.2.1 Turn on the printer power supply.
When the power is turned on, the printer begins a self-test operation (the printhead carriage and the
feed rollers move). When the self test has been completed, wait until the main menu is displayed on
the LCD.
Since ink has not yet been supplied to the printer, a "No Ink" alarm will sound after several
minutes have elapsed. This alarm does not indicate a malfunction, and no action is required.
SignJet JS310 Series Set Up Guide
cleaning solution from the sub tanks into the waste ink tanks.
•
CAUTION: When opening the cap, be sure to
grasp the upper corners of the tank.
Tilt the sub tank, and then pour the
cleaning solution into the waste ink
tank positioned underneath it.
- 32 -
