VI.3 LCD display for normal usage
VI.3.1 LCD display during printing
Printing
Online
The LCD displays total lines for printing, lines finished and lines of RIP ready during printing.
VI.3.2 LCD display when printing is paused
P/H nozzles may be clogged during printing, so it needs cleaning.
Press and hold ONLINE key to pause the printing until the LCD displays "Busy". The P/H carriage returns
to original position after it finishes the current line printing. The LCD displays menus as below:
Waiting
Online
Press ▲ or ▼ key to select "Cleaning tool" function in the menu and execute cleaning.
Select "Continuous" to continue printing or "Cancel" to cancel printing.
SignJet JS310 Series User's Manuals
TOTAL: XXXX
FINISH: XXXX
RIP READY: XXXX
1. Ink status
2. Heat status
3. Cleaning tool
4. Continuous
Cancel
5.
Total lines for printing
Lines finished
Lines of RIP ready
- 32 -
