Comtech EF Data CDM-625A Installation And Operation Manual page 98

CDM-625A Advanced Satellite Modem
Updating Firmware
Step Task
3
Confirm availability of the firmware files in the temporary folder. There are a number of ways the user may view the
contents of the temporary folder on a Windows-based PC:
A. From the Windows Desktop:
Double-left-click the "temp" folder saved to the Windows Desktop.
•
Use Windows Explorer to locate, and then double-left-click the "temp" folder.
•
Use t he ' Browse' w indow ( [Start] > .. .Run > [ Browse]) to l ocate, and then d ouble-click t he " c:\temp"
•
folder.
B. Using Command-line:
Type "cd c:\temp" at the pr ompt to change to the temporary directory created earlier using Command-
•
line.
Type "dir" to list the files extracted to the temporary directory from the downloaded archive file.
•
The firmware files have been successfully downloaded to the user PC and are now available for FTP
upload to the CDM-625A.
4–6
Revision 0
MN-CDM625A
