Comtech EF Data CDM-625A Installation And Operation Manual page 318

CDM-625A Advanced Satellite Modem
Serial-based Remote Product Management
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
G.703 Clock CEX= 2 bytes
Extension
Tx BERT State BTX= 1 byte, value of 0
or 1
Rx BERT State BRX= 1 byte, value of 0
or 1
Tx BERT TBP= 1 byte
Pattern
Description of Arguments
Command or Query. (FAST option)
G.703 Clock Extension in the form ab, where:
a = G.703 Clock Extension Mode
0 = None
1 = TxLock
2 = RxEnable
b = G.703 Clock Extension Interface
0 = T1
1 = E1Bal
2 = E1Unbal
Example: CEX=12 (Sets Tx Lock to E1 Unbalanced)
Notes:
1. Not all CEX modes are valid all the time.
2. For argument a:
If Data Interface (ITF) is G.703, only 0=None is allowed.
If Tx clock (TCK) is not Internal, 1=TxLock is not allowed.
Command or Query.
Tx BERT State in the form x, where:
0 = Off
1 = On
Example: BTX=1 (Tx BERT On)
Command or Query.
Rx BERT State in the form x, where:
0 = Off
1 = On
Example: BRX=1 (Rx BERT On)
Command or Query.
Tx BERT Pattern, in the form x, where:
0=space
1=mark
2=1:1
3=1:2
4=63
5=511
6=2047 (default)
7=2047R (or 2047 Alternate)
8=Mil-188
9=2^15-1
A=2^20-1
B=2^23-1
Example: TBP=6 (Tx BERT Pattern is 2047)
8–36
Revision 0
MN-CDM625A
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
CEX= CEX? CEX=ab
CEX? (see Description of
CEX* Arguments)
CEX#
BTX= BTX? BTX=x
BTX? (see Description of
BTX# Arguments)
BRX= BRX? BRX=x
BRX? (see Description of
BRX# Arguments)
TBP= TBP? TBP=x
TBP? (see Description of
TBP# Arguments)
