Comtech EF Data CDM-625A Installation And Operation Manual page 314

CDM-625A Advanced Satellite Modem
Serial-based Remote Product Management
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
Number of N/A 3 bytes
Unread stored
Statistics
Retrieve next 5 N/A 135 bytes
unread Stored
Statistics
Retrieve next N/A 180 bytes
5 unread New
Stored
Statistics
Clear All CAS= None
Stored
Statistics
Initialize ISP= None
Statistics
Pointer
Description of Arguments
Query only.
Unit returns the number of stored Statistics, which remain Unread (over remote control) in the form xxx, where:
x = 0-255
Example: NUS=187
Query only.
Unit returns the oldest 5 Stored Statistics, which have not yet been read over the remote control in the reply format
[CR]sub-body[CR]sub-body[CR]sub-body[CR]sub-body[CR]sub-body, where sub-body=
AA.ABB.BC.CD.Dddmmyyhhmmss:
AA.A=Minimum Eb/No during sample period.
BB.B=Average Eb/No during sample period.
C.C=Max. Tx Power Level Increase during sample period.
D.D=Average Tx Power Level Increase during sample period.
ddmmyy = date stamp.
hhmmss = time stamp.
If there are no new events, the unit replies with RNS*. If there are less than 5 statistics to be retrieved, the remaining
positions are padded with zeros.
Query only.
Unit returns the oldest 5 Stored Statistics (including newly added Minimum and Average Receive Signal level), which have
not yet been read over the remote control in the reply form [CR]sub-body[CR]sub-body[CR] sub-body[CR]sub-
body[CR]sub-body, where sub-body = AA.ABB.BC.CD.DEE.E,FF.Fddmmyyhhmmss:
AA.A=Minimum Eb/No during sample period.
BB.B=Average Eb/No during sample period.
C.C=Max. Tx Power Level Increase during sample period.
D.D=Average Tx Power Level Increase during sample period.
EE.E=Negative value of Minimum Receive Signal Level in dB during sample period.
FF.F=Negative value of Average Receive Signal Level in dB during sample period.
ddmmyy = date stamp.
hhmmss = time stamp.
If there are no new events, the unit replies with RNN*. If there are less than 5 statistics to be retrieved, the remaining
positions are padded with zeros.
Note: RNN includes all information provided in RNS, plus Rx Signal level. Do not mix use of RNS and RNN.
Command only.
Forces the software to clear the software statistics log.
Example: CAS=
Note: This command takes no arguments.
Command only.
Resets internal pointer to allow RNS? queries to start at the beginning of the statistics log.
8–32
Revision 0
MN-CDM625A
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
N/A NUS? NUS=xxx
(see Description of
Arguments)
N/A RNS? RNS=[CR]AA.ABB.BC.
CD.Dddmmyyhhmmss
[CR]AA.ABB.BC.CD.D
ddmmyyhhmmss[CR]A
A.ABB.BC.CD.Dddmm
yyhhmmss[CR]AA.AB
B.BC.CD.Dddmmyyhh
mmss[CR]AA.ABB.BC.
CD.Dddmmyyhhmmss
(see Description of
Arguments)
N/A RNN? RNN=[CR]AA.ABB.BC
.CD.DEE.E,FF.Fddmm
yyhhmmss[CR]AA.AB
B.BC.CD.DEE.E,FF.Fd
dmmyyhhmmss[CR]A
A.ABB.BC.CD.DEE.E,
FF.Fddmmyyhhmmss[
CR]AA.ABB.BC.CD.D
EE.E,FF.Fddmmyyhh
mmss[CR]AA.ABB.BC.
CD.DEE.E,FF.Fddmm
yyhhmmss
(see Description of
Arguments)
CAS= N/A N/A
CAS?
CAS*
CAS#
ISP= N/A N/A
ISP#
