Comtech EF Data CDM-625A Installation And Operation Manual page 307

CDM-625A Advanced Satellite Modem
Serial-based Remote Product Management
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
Rx Ternary RTC= 1 byte, value of
Code 0 thru 3
Receive RBA= 4 bytes, each a
Backward value of 0 or 1
Alarms Enable
Receive ESC RET= 1 byte, 0 or 1
Type
Insert Timeslot ITS= 3 bytes
ReCenter RCB= None
Buffer
RX LO RLO= 6 bytes
Frequency
Description of Arguments
Command or Query. (G.703 parameter)
Rx Ternary Code in the form x, where:
0=AMI
1=B8ZS
2=B6ZS
3=HDB3
Example: RTC=1 (selects B8ZS)
Command or Query. (IDR parameter)
Enable Receive backward alarm enable in the form xxxx, where:
0=Disable
1=External trigger Enable
Example: RBA=0101
Command or Query. (IDR parameter)
Sets or queries IDR ESC Type in the form x, where:
0=64k data channel
1=2 Audio channels
Command or Query. (D&I/D&I++ only)
(Note different format between command and query.)
Insert Timeslot in the form xxy, where:
xx = Channel 01 through 24
y = timeslot: 0-9, A=10, B=11, C=12, D=13,...V=31
Command only.
Forces the software to recenter the receive Plesiochronous/Doppler buffer.
Note: This command takes no arguments.
Example: RCB=
Command or Query.
LNB Rx LO frequency information in the form xxxxxs, where:
xxxxx is the LO frequency: 03000 through 65000 MHz, or 00000=Off
s is the sign for the MIX (Note: negative mix induces a spectral inversion)
Note: For additional information refer to Chapter 6 for LO, MIX, and Spectrum Settings.
Terminal Frequency = RX LO ± modem RFQ (see below)
8–25
Revision 0
MN-CDM625A
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
RTC= RTC? RTC=x
RTC?
RTC* (see Description of
RTC# Arguments)
RBA= RBA? RBA=xxxx
RBA?
RBA* (see Description of
RBA# Arguments)
RET= RET? RET=x
RET?
RET* (see Description of
RET# Arguments)
ITS= ITS? ITS=yyyyyyyyyyyyyyy
ITS? yyyyyyyyy
ITS* indicating all 24 Insert
ITS# timeslots values
associated with the 24
Rx Satellite channels.
RCB= N/A N/A
RCB?
RCB*
RCB#
RLO= RLO? RLO=xxxxxs
RLO?
RLO* (see Description of
RLO# Arguments)
