CDM-625A Advanced Satellite Modem
Serial-based Remote Product Management
Command
Parameter
Number of
(Instruction
Type
Arguments
& Qualifier)
Software
N/A
38 bytes
Revision 2
Equipment ID
N/A
33 bytes
Description of Arguments
Query only.
Unit returns the value of the internal software revision installed in the unit,
Example: SW2=Boot:2.1.1 Bulk1*:2.1.2 Bulk2 :2.1.1
The current active image is indicated with an asterisk.
Query only.
Unit returns the equipment ID and installed options in the form AAAABCDEFGHsJKLMNPQRSTUVWXYssssss, where:
AAAA=A625, the modem model number
Installed hardware:
B=Slot 1: TPC/LDPC codec, where:
0 = not present
1=present
C=0 (Reserved for Expansion board)
D=0 (Reserved for VersaFEC-2 board)
E=Slot 4: Network Processor card, where:
0 = not present
1 = present
F=spare (0)
G=External 20dB attenuator, where:
0 = not present
1 = present
H=Audio chips, where:
0=not present
1 = present
s=spares (0)
Software FAST options:
J=Frequency option, where:
0=70/140MHz
1= 70/140MHz & L-Band
K=Modulation option, where:
0=Standard: BPSK, QPSK, OQPSK.
1=Option 0 plus 8-ARY
2=Option 0 plus 16-ARY
3=Option 1 and option 2
L=Data Rate option
M=TPC/LDPC data rate option
For L and M, the value is decoded:
0=Base, up to 5Mbps
1=up to 10Mbps
2=up to 15 Mbps
3=up to 20Mbps
4=up to 25Mbps
N=CnC data rate option, where:
0=No CnC FAST installed
1=up to 512kbps
2=up to 1.1Mbps
3=up to 2.5 Mbps
8–47
Revision 0
MN-CDM625A
Query
Response to
(Instruction &
Response to Query
Command
Qualifier)
N/A
SW2?
SW2=x
(see Description
of Arguments)
N/A
EID?
EID=AAAABCDEFGHs
JKLMNPQRSTUVWXY
Zabssss
(see Description of
Arguments)
